IC695PNC001 | highly – regarded PROFINET controller module
Product Overview
The IC695PNC001 is a highly – regarded PROFINET controller module belonging to the GE Fanuc PACSystems RX3i series, now under Emerson Automation. Its core function is to establish a seamless connection between the RX3i controller and a high – speed PROFINET local area network. In an industrial automation setup, this module is of utmost importance as it enables the RX3i controller to communicate effectively with various PROFINET IO devices. This communication is crucial for tasks such as controlling connected sensors, actuators, and other devices, as well as for data acquisition and transmission. The IC695PNC001 stands out due to its high – speed data transfer capabilities, compliance with the PROFINET IO v2.2 standard, and its flexibility in configuration, making it suitable for a wide range of industrial applications.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | IC695PNC001 |
| Manufacturer | Emerson (formerly GE Intelligent Platforms) |
| Product Type | PROFINET Controller Module |
| Communication Protocol | PROFINET IO v2.2 |
| Data Rate | Supports 100 Mbps and 1 Gbps for PROFINET communication |
| Number of Supported Devices per Controller | Up to 64 |
| Number of I/O Controllers per Network | Up to 8 |
| Maximum I/O Devices per Controller | Up to 2048; up to 128 per network |
| Interface Types | Two RJ – 45 and two SFP slots, one micro USB connector |
| Configurable Data Update Time | 1 ms, 2 ms, 4 ms, 8 ms, 16 ms, 32 ms, 64 ms, 128 ms, 256 ms, 512 ms |
| Mounting Type | DIN – rail mountable (part of the overall system’s mounting scheme) |
| Operating Temperature Range | 0 – 60 °C |
Key Features and Benefits
The IC695PNC001 offers several significant features. Its high – speed communication capabilities, with support for 100 Mbps and 1 Gbps PROFINET data rates, ensure rapid data transfer between the RX3i controller and connected devices. This is essential in applications where real – time control and monitoring are required, such as in high – speed production lines.
It is fully compliant with the PROFINET IO v2.2 standard, which means it can be easily integrated into existing PROFINET networks. This compliance also ensures compatibility with a wide range of PROFINET – enabled devices, enhancing the flexibility of the overall automation system.
The module’s flexible configuration options allow it to adapt to different application needs. Whether it’s a small – scale industrial setup or a large – scale complex system, the IC695PNC001 can be configured to meet the specific requirements, such as adjusting the data update time according to the criticality of data transfer.
In terms of reliability, the IC695PNC001 is designed for industrial environments. It can withstand harsh conditions within its specified operating temperature range, reducing the risk of system failures due to environmental factors. Additionally, it has diagnostic features, like an internal clock synchronized with the RX3i CPU for time – stamped diagnostics entries, which helps in quickly identifying and resolving issues.
The IC695PNC001 also has a built – in command – line interface function. This function allows for direct monitoring and partial configuration either via the micro USB port or using telnet, providing users with convenient ways to manage and maintain the module.
It is fully compliant with the PROFINET IO v2.2 standard, which means it can be easily integrated into existing PROFINET networks. This compliance also ensures compatibility with a wide range of PROFINET – enabled devices, enhancing the flexibility of the overall automation system.
The module’s flexible configuration options allow it to adapt to different application needs. Whether it’s a small – scale industrial setup or a large – scale complex system, the IC695PNC001 can be configured to meet the specific requirements, such as adjusting the data update time according to the criticality of data transfer.
In terms of reliability, the IC695PNC001 is designed for industrial environments. It can withstand harsh conditions within its specified operating temperature range, reducing the risk of system failures due to environmental factors. Additionally, it has diagnostic features, like an internal clock synchronized with the RX3i CPU for time – stamped diagnostics entries, which helps in quickly identifying and resolving issues.
The IC695PNC001 also has a built – in command – line interface function. This function allows for direct monitoring and partial configuration either via the micro USB port or using telnet, providing users with convenient ways to manage and maintain the module.
Related Models
- IC695PNC002: May be an upgraded version with enhanced features, perhaps improved communication speed or additional configuration options compared to the IC695PNC001.
- IC693PNC001: From a different but related series, it might have different form factors or be designed for applications with different scale requirements, like smaller – scale industrial setups.
- IC695PWR001: A power – related module in the RX3i series. It is related as it provides the necessary power for the IC695PNC001 and other components in the system to function properly.
- IC695CPU310: The CPU module in the RX3i series. The IC695PNC001 works in tandem with this CPU, with the CPU processing data and the IC695PNC001 handling the PROFINET network communication.
- IC695ALG220: An analog I/O module in the series. The IC695PNC001 can communicate with this module to transfer analog data between the RX3i system and external analog – based devices in the PROFINET network.
