Schneider Electric 140CPU67160 is a high – performance programmable logic controller (PLC)
Product Overview
The Schneider Electric 140CPU67160 is a high – performance programmable logic controller (PLC) designed to meet the demands of complex industrial automation scenarios. As part of the Modicon Quantum series, it plays a crucial role in automation setups by providing reliable control and efficient operation. This PLC is engineered to handle a wide array of control tasks, making it an invaluable asset in various industries. It can manage multiple input and output signals, allowing for seamless integration with sensors and actuators. The 140CPU67160 is highly adaptable, whether used in small – scale manufacturing lines or large – scale industrial plants, offering a stable and efficient control solution.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | 140CPU67160 |
| Manufacturer | Schneider Electric |
| Product Type | Programmable Logic Controller (PLC) |
| Input Voltage | 24 VDC |
| Power Consumption | 5 W |
| Program Memory | 2 MB |
| Execution Time | 0.5 ms/k |
| Number of I/O Points | 64 inputs, 64 outputs |
| Communication Interfaces | Modbus, Ethernet/IP, Profibus |
| Operating Temperature Range | – 10 °C to + 60 °C |
| Protection Rating | IP20 |
| Memory Capacity (RAM) | 64 KB |
| Memory Capacity (Flash) | 256 KB |
Key Features and Benefits
The Schneider Electric 140CPU67160 offers several distinct features that set it apart. Its high – speed processing capabilities ensure rapid response times. With an execution time of 0.5 ms per k instruction, it can handle critical processes without delay. The 2 MB of program memory provides extensive space for complex control logic programming. This means that even the most intricate control tasks can be executed smoothly.
The 140CPU67160 supports multiple communication interfaces such as Modbus, Ethernet/IP, and Profibus. This wide range of connectivity options enables easy integration with other devices and systems in an industrial network. It allows for efficient data exchange, which is essential for real – time monitoring and control.
In terms of reliability, the PLC is built to last. It can operate within a relatively wide temperature range of – 10 °C to + 60 °C, making it suitable for harsh industrial environments. The IP20 protection rating safeguards it against dust and light splashes, further enhancing its durability.
Application Scenarios
In power plants, the Schneider Electric 140CPU67160 can be used to control the operation of various systems. For example, it can manage the start – up and shut – down sequences of generators, ensuring smooth transitions and preventing potential damage. In oil & gas refineries, it plays a vital role in controlling the flow of fluids through pipelines. By accurately processing input signals from sensors that monitor pressure, temperature, and flow rate, the 140CPU67160 can adjust valves and pumps to maintain optimal operating conditions.
In discrete manufacturing lines, such as those producing automotive parts, the PLC can control the movement of robotic arms. It can precisely time the actions of the arms to pick, place, and assemble components, increasing production efficiency and product quality. In smart infrastructure projects, like intelligent buildings, the 140CPU67160 can be used to manage lighting, heating, and ventilation systems. It can adjust these systems based on occupancy sensors and environmental conditions, leading to energy savings.
Related Models
- 140CPU43412 – A previous – generation model with a lower processing speed and less memory capacity, suitable for less complex automation tasks.
- 140CPU11302 – A more basic model with a simpler architecture, designed for small – scale applications where cost – effectiveness is a priority.
- 140ACI04000 – An input module that can be used in conjunction with the 140CPU67160 to expand the number of input channels in an automation system.
- 140CHS11000 – A communication module that enhances the networking capabilities of the 140CPU67160, providing additional options for data transfer within an industrial network.
- 140CPS11400 – A power supply module that can be used to power the 140CPU67160 and other components in the same system, ensuring stable operation.
Installation and Maintenance
Installation preparation for the 140CPU67160 requires ensuring an appropriate physical space. The module has compact dimensions, but it should be installed in an area with enough room for proper ventilation. Grounding is crucial to protect the device from electrical surges. It should be mounted on a stable surface following the provided mounting instructions. The operating environment should be within the specified temperature range of – 10 °C to + 60 °C.
For maintenance, regular checks of the communication interfaces are recommended to ensure seamless data transfer. Monitoring the power consumption can also help detect any potential issues. The PLC should be inspected for any signs of physical damage. As for replacement intervals, the battery (if applicable) should be replaced according to the manufacturer’s guidelines. Software updates should be installed periodically to keep the 140CPU67160 running with the latest features and security patches.
Product Warranty
Schneider Electric stands behind the quality of the 140CPU67160 with a comprehensive warranty. The warranty coverage ensures that in case of any manufacturing defects, the product will be repaired or replaced. Global support is available, so customers anywhere in the world can access assistance. The company is committed to customer satisfaction and aims to resolve any issues promptly. Whether it’s a technical query or a warranty claim, Schneider Electric’s support team is ready to provide the necessary help, giving customers confidence in their investment in the 140CPU67160 for their industrial automation needs.
