Module Type:High-Speed Analog Input Module
Model:700-ADL3R
Brand:Rockwell Automation
Compatibility:Compatible with Allen Bradley ControlLogix series
Input Channels:3 channels
Input Range:±10V or ±5V
Resolution:16-bit
Sampling Rate:Up to 250 kS/s per channel
Power Supply:24V DC
Operating Temperature:-40°C to +85°C
Dimensions:Width: 21.6mm, Height: 86.4mm, Depth: 101.6mm
Weight:0.2 kg
The Rockwell Automation 700-ADL3R Plug-In Module is a critical component for enhancing the performance of automation systems. Designed with precision engineering, this module ensures seamless integration with Allen Bradley ControlLogix series PLCs, making it a staple in modern industrial control setups.
It offers robust signal processing capabilities, allowing for accurate and reliable data acquisition at speeds up to 100kHz. The wide input range of 0-10V DC or 4-20mA makes it versatile for various applications, from process monitoring to control system optimization.
Engineered for durability, this module can operate under extreme conditions, handling temperatures ranging from -40°C to 85°C. Its compact design, measuring 2.0 x 2.5 x 0.5 inches, ensures easy installation in tight spaces without compromising performance.
With a lightweight design weighing just 0.15 lbs, the 700-ADL3R module is perfect for installations where weight is a consideration. The power supply requirement is between 10-30V DC, ensuring compatibility with a wide range of power sources commonly found in industrial environments.
Installation is straightforward, with clear guidelines provided in the user manual. Its modular nature allows for quick and efficient upgrades or replacements, minimizing downtime and maximizing productivity.
