Brand:General Electric
Model:DS3800HPBD1D1C
Module Type:Speedtronic Turbine Control Board
Power Port:Large power port on one edge
Connection Method:Clips and screws
LEDs:Around twenty different colored diodes, including two red LEDs
Toggle Switch:Small silver toggle switch
Jumper Ports:Several pairs of metal pins with black covers
The DS3800HPBD1D1B module is engineered for robust performance and reliability within the Mark IV Speedtronic system. Designed for seamless integration with Mark IV turbine controls, this module provides essential functions critical to turbine operation. It features a large power port located along one edge, making it easy to connect to the power supply. The module incorporates approximately twenty diodes of various colors and sizes, which serve as visual indicators for system status. Two red LEDs offer clear and immediate alerts for critical conditions. The small silver toggle switch allows for manual intervention when needed. Additionally, the DS3800HPBD1D1B includes multiple pairs of metal pins, known as jumper ports, covered with black caps, allowing for flexible adjustments and customization of energy settings. All connections are designed for compatibility with standard female harnesses, ensuring secure and reliable connections every time. With a design that prioritizes durability and ease-of-use, the DS3800HPBD1D1B is an indispensable component for any industrial turbine control setup.
