Input Voltage Range:24V DC
Common Mode Voltage Range:-20 to +20 VDC
Absolute Input Voltage:±7.5 VDC or ±7.5 VAC RMS (Max.)
Input Range:-20 to +20 mA
Isolation:500 VDC
Number of Channels:8
Operating Voltage:5 to 30V DC or 5 to 250V AC
Current Rating:Backplane Current Draw: 35mA at 5V, 85mA at 24V
The AB 1746-IV8 DC Input Module is engineered to meet the stringent demands of industrial environments. With its robust design and high current capacity, it ensures reliable signal acquisition and transmission under challenging conditions.
Each channel of the module supports a maximum of 20mA, allowing for precise measurement of various electrical parameters. The wide voltage range accommodates diverse applications across different industries, ensuring compatibility and flexibility.
Operated within an expansive temperature range from -40°C to +70°C, this module is suitable for use in both harsh and moderate climates, making it ideal for outdoor or factory floor installations.
The module’s industrial enclosure provides protection against dust, moisture, and physical impacts, ensuring longevity and reliability in demanding environments. The use of terminals simplifies connection and disconnection procedures, enhancing maintenance efficiency.
Supporting the RS-485 communication protocol, the AB 1746-IV8 enables seamless integration with other Allen-Bradley components and third-party devices, facilitating easy setup and operation within complex automation systems.
