MAGNETEK 4005-G+S3 Product Description

Product Overview

The MAGNETEK 4005-G+S3 is a high-performance industrial motor controller engineered to deliver precise and reliable operation in a variety of automation systems. As a key model in Magnetek’s lineup of control solutions, this device integrates advanced control algorithms with durable hardware, making it suitable for applications ranging from small machinery to medium-duty industrial equipment. Whether used in material handling systems, packaging lines, or auxiliary industrial motors, the 4005-G+S3 ensures efficient motor management, enhanced safety, and seamless integration with existing control architectures. Its compact design and user-centric features make it a practical choice for engineers seeking to optimize motor performance while minimizing operational complexity.

Hainan Jinlin Mechanical & Electrical, a distributor of industrial control products, specializes in a wide range of brands. With extensive industry knowledge and market insights, we adhere to the “Customer First, Forge Ahead” business philosophy, providing high-quality customer service to meet your needs.

Technical Specifications

Parameter	Value
Product Model	4005-G+S3
Manufacturer	MAGNETEK
Product Type	Motor Controller
Rated Current	5 A
Motor Power Range	0.75 kW – 2.2 kW (at 400V AC)
Input Voltage	200V – 480V AC, 3-phase
Control Modes	Direct-on-line, soft start (optional)
Operating Temperature	-5°C to +45°C
IP Rating	IP21 (enclosure)

Key Features and Benefits

Versatile Motor Control

The MAGNETEK 4005-G+S3 offers flexible control options, including direct-on-line starting for simple applications and optional soft start functionality for scenarios requiring gentler motor acceleration. This versatility allows it to adapt to diverse motor types and operational demands, from small fans and pumps to light-duty conveyors. The direct-on-line mode ensures quick and reliable startup for basic systems, while the optional soft start feature minimizes inrush current and mechanical stress, extending motor lifespan in more delicate applications.

Compact and Space-Efficient Design

With its compact form factor, the 4005-G+S3 is ideal for installations where space is limited, such as control cabinets with multiple components. Its streamlined design allows for easy mounting alongside other control devices, reducing the overall footprint of the automation system. This space efficiency is particularly valuable in modern industrial facilities where optimizing cabinet space is crucial for both cost and operational efficiency.

Comprehensive Safety Features

Equipped with essential protective mechanisms, the MAGNETEK 4005-G+S3 safeguards motors against overload, short circuits, and phase imbalances. The overload protection is adjustable to match the motor’s specifications, ensuring precise protection without unnecessary interruptions. Phase imbalance detection prevents motor damage caused by uneven power distribution, while short-circuit protection limits current flow to safe levels, protecting both the motor and the controller itself. These features minimize the risk of equipment failure and enhance overall system safety.

Easy Installation and Operation

The 4005-G+S3 is designed for straightforward installation and user-friendly operation. Its clear wiring terminals and intuitive interface simplify setup, reducing installation time and the need for specialized expertise. The controller’s status indicators provide visual feedback on operational status, making it easy for operators to monitor performance and identify issues quickly. Additionally, it supports basic remote control via auxiliary contacts, enabling integration with simple PLC systems or manual control panels for enhanced operational flexibility.

Related Models

As a certified partner of industry leaders such as Bentley Nevada, Honeywell, and ABB, we provide key components for various application areas. In process industries, the MAGNETEK 4005-G+S3 controls small agitators and auxiliary pumps in pharmaceutical and cosmetic production lines. In discrete manufacturing, it regulates motor-driven components in packaging machinery and small assembly stations. In infrastructure, it manages motorized valves and small HVAC systems in commercial buildings. We offer a one-year warranty for the MAGNETEK 4005-G+S3. If you cannot find the model you need, please contact us immediately.
