Schneider Electric 140DAI35300 is a discrete input module

Product Overview

The Schneider Electric 140DAI35300 is a discrete input module that plays a crucial role in industrial automation setups. It is part of the Modicon Quantum series, which is renowned for its versatility and high – performance in handling complex processes. This module is designed to receive and process digital input signals, making it an essential component for systems that need to monitor the status of switches, sensors, and other binary – state devices.



With 140DAI35300, industrial facilities can accurately detect the on – off states of various field devices. It provides a reliable interface between the real – world equipment and the control system, ensuring seamless data flow. In an automation system, it acts as the eyes and ears, collecting vital information from the plant floor and relaying it to the central control unit. Its value lies in its ability to enhance the overall reliability and precision of the automation process, making it suitable for a wide range of industrial applications.

Technical Specifications

Parameter Value
Product Model 140DAI35300
Manufacturer Schneider Electric
Product Type Discrete Input Module
Number of Inputs 32 (4 groups of 8)
Operating Voltage 24 VAC
Backplane Output Current 250 mA
Operating Temperature 0 – 60 °C
Approval UL 508, cUL, CSA C22.2, CE
Response Time (on to off) 7.3 – 12.3 milliseconds
Mounting Chassis
Input Signal Type Sinusoidal with less than 65% THD, max 60Hz frequency
Input Impedance (60Hz, ON) 2.6 kΩ (capacitive regime)
Input Impedance (60Hz, OFF) 3.1 kΩ (capacitive regime)

Key Features and Benefits

The 140DAI35300 offers several practical strengths. First, its high number of 32 discrete inputs allows for the connection of a large number of field devices in a single module. This reduces the need for multiple smaller modules, simplifying the system architecture and saving on installation space and costs.

Kawasaki P/N 50979-0360L05 Teach Pendant Cable - Industrial Control Solutions

It has a wide operating voltage range of 24 VAC, making it compatible with many industrial power systems. The module is also designed to operate within a temperature range of 0 – 60 °C, ensuring reliable performance in diverse environmental conditions.



In terms of diagnostic support, it can accurately detect the status of input signals. If there are any issues with the connected devices, such as a sensor malfunction or a broken wire, the module can quickly identify the problem. This helps in minimizing downtime as maintenance personnel can quickly address the root cause.



The 140DAI35300 is also known for its robust build quality. With approvals like UL 508, cUL, CSA C22.2, and CE, it meets international safety and quality standards. This gives users confidence in its reliability and durability, even in harsh industrial settings.

Application Scenarios

The Schneider Electric140DAI35300
has numerous realistic use cases across different industries. In manufacturing plants, it can be used to monitor the status of conveyor belts, where switches are installed to detect the presence or absence of products. The module can receive these signals and send the information to the control system, which can then adjust the speed of the conveyor or trigger an alarm if there is a blockage.



In oil and gas refineries, it can be used to monitor the open – close status of valves. By connecting to position sensors on the valves, the 140DAI35300 can inform the control system whether a valve is fully open, closed, or in an intermediate position. This is crucial for ensuring the safe and efficient operation of the refinery processes.



For power plants, the module can be used to monitor the status of circuit breakers. When a circuit breaker trips, the associated switch sends a signal to the 140DAI35300, which then notifies the control system. This allows for quick response times to prevent further damage to the power generation and distribution equipment.

Related Models

  • 140DAI35200 – A related module with a different input configuration, perhaps having fewer input points or different voltage requirements, suitable for less complex applications where a smaller number of discrete inputs are needed.
  • 140DAI54500 – May offer enhanced features such as better noise immunity or faster response times, making it more suitable for high – speed or noisy industrial environments compared to the 140DAI35300.
  • 140ACI04000 – An analog input module from the same series, which is used when the control system needs to handle analog signals rather than discrete signals like the 140DAI35300 does.
  • 140CPS11420 – A power supply module that can be used in conjunction with the140DAI35300
  • to ensure a stable power source for the overall Quantum system.
  • 140CPU65160 – A high – performance processor module in the Quantum series. The 140DAI35300 can be integrated with this processor to form a complete and powerful control system for complex industrial processes.

Installation and Maintenance

Installation preparation for the 140DAI35300 requires a suitable chassis for mounting. Ensure that the physical space where the module will be installed is clean and free from any obstructions. Grounding is crucial to protect the module from electrical surges. The environment should be within the specified temperature range of 0 – 60 °C.

Xu Gong AK-BX556M Control/Interface Module - Reliable Automation Solutions

During installation, carefully follow the provided wiring diagrams to connect the input signals correctly. Incorrect wiring can lead to malfunctioning of the module or inaccurate readings.



For maintenance, it is recommended to regularly check the input signals for any anomalies. This can be done by monitoring the status indicators on the module or through diagnostic software. If any input channels show inconsistent readings, it may be a sign of a problem with the connected device or the module itself. As for replacement intervals, while the 140DAI35300 is built to be durable, if it shows signs of physical damage or frequent malfunctions, it may be time to consider replacement. In general, periodic visual inspections and functional tests can help in maintaining the module’s optimal performance.

Product Warranty

We are confident in the quality of the Schneider Electric 140DAI35300. It comes with an 18 – month warranty. During this period, if the module experiences any defects in materials or workmanship, we will provide prompt replacement or repair services. Our global support network is always available to assist customers. Whether you are located in a major industrial hub or a remote area, our team of experts can offer technical advice and support. We are committed to customer satisfaction and strive to ensure that the 140DAI35300 performs reliably throughout its lifespan. This warranty not only reflects the high – quality standards of the product but also our dedication to providing long – term value to our customers.
2025-06-19 BY
IN Company News

Schneider Electric  140CPU67260  | Unity Hot Standby Processor

Product Overview

The Schneider Electric  140CPU67260  is a Unity Hot Standby Processor, an integral part of the Modicon Quantum automation platform. This high – performance unit is designed to meet the demands of industrial automation setups where continuous operation is crucial. In an automation system, it acts as the central processing unit, responsible for executing control programs, managing data, and coordinating communication between various components.



The 140CPU67260 stands out for its hot standby redundancy feature. In critical applications, it ensures that there is no interruption in operation even if the primary processor fails. The multimode Ethernet functionality provides network flexibility, allowing for seamless connection with a wide range of devices in the industrial network. With its 266 MHz clock speed, it can rapidly process instructions, enabling real – time control in complex industrial processes.

Technical Specifications

Parameter Value
Product Model 140CPU67260
Manufacturer Schneider Electric
Product Type Unity Hot Standby Processor
Processor Type RISC
Clock Speed 266 MHz
Internal Memory 3072 kb (1536 kb for data), expandable
Communication Multimode Ethernet, Modbus, Modbus Plus, Profibus DP, TCP/IP
I/O Support A wide range of I/O modules
Operating Temperature – 20 °C to 60 °C (- 4 °F to 140 °F)
Storage Temperature – 40 °C to 85 °C (- 40 °F to 185 °F)
Humidity 5% to 95% non – condensing
Vibration 0.5 g rms, 5 to 500 Hz
Shock 15 g, 11 ms half – sine
EMC Complies with EN 61000 – 6 – 2, EN 61000 – 6 – 3

Siemens 6DD1688-1AA0 Interface Module, Advanced Automation Solution

Key Features and Benefits

The 140CPU67260  offers several practical strengths. Its hot standby redundancy is a game – changer for industries where downtime is not an option. In the event of a primary processor failure, the standby processor can take over instantaneously, minimizing any disruption to the industrial process. This feature is especially valuable in continuous – production environments such as chemical plants or power generation facilities.



The multimode Ethernet connectivity allows for high – speed and reliable data transfer. It can communicate with different types of devices on the network, whether they are other PLCs, HMIs, or sensors. This flexibility in communication protocols means that the 140CPU67260 can be easily integrated into existing industrial networks without major re – engineering.



With a 266 MHz clock speed, it provides fast processing of control programs. This speed is essential for real – time applications, like high – speed manufacturing lines where quick decisions based on sensor data are required. The expandable memory feature is another advantage. As industrial applications grow and more data needs to be stored or more complex control algorithms need to be implemented, the ability to add more memory via PCMCIA cards ensures that the 140CPU67260  can keep up with the demands.

Application Scenarios

The Schneider Electric 140CPU67260  has a wide range of application scenarios. In power plants, it can be used to control and monitor the generation, transmission, and distribution of electricity. For example, it can manage the operation of turbines, ensuring that they run at optimal efficiency. In case of any faults in the primary control system, the hot standby feature of the 140CPU67260 will kick in, preventing any interruption in power supply.



In oil & gas refineries, the processor is used to control the complex processes involved in refining crude oil. It can monitor and adjust variables such as temperature, pressure, and flow rates in real – time. The reliable communication and fast processing capabilities of the 140CPU67260 are crucial in these hazardous environments, where accurate and timely control is necessary to prevent accidents.

MKS 0100-01577 PCB Board: Precision Electronics for Industrial Control Solutions

Discrete manufacturing lines also benefit from the 140CPU67260. In an automotive assembly line, for instance, it can control the movement of robotic arms, conveyor belts, and other machinery. The hot standby redundancy ensures that production can continue even if there is a problem with the main control unit, reducing costly production stoppages.

Related Models

  • 140CPU65150 – An earlier version with lower processing power and less memory, suitable for less complex industrial applications.
  • 140CPU67160 – A model with similar functionality but without the hot standby feature, which can be used in applications where redundancy is not a top priority.
  • 140NOE77101 – An Ethernet communication module that can be used in conjunction with the 140CPU67260 140CPU67260 to enhance network connectivity.
  • 140CPS11420 – A power supply module compatible with the Modicon Quantum platform, including systems with the 140CPU67260.
  • 140ACI04000 – An analog input module that can be integrated into a system using the 140CPU67260 for applications that require monitoring of analog signals.

Installation and Maintenance

Installation preparation for the 140CPU67260 requires ensuring there is sufficient physical space in the control cabinet. The mounting method is typically designed to fit standard industrial racks, and proper grounding is essential to protect the unit from electrical surges. The environment should be within the specified temperature and humidity ranges, as extreme conditions can affect its performance.



For maintenance, regular checks should include monitoring the status LEDs on the processor to ensure normal operation. Periodically, the communication connections should be inspected to make sure there are no loose cables or signs of wear. The internal memory can be checked for any errors or signs of low storage capacity. While the 140CPU67260 is a robust device, it is recommended to plan for replacement every 5 – 7 years, depending on the operating environment and usage intensity. This proactive approach can help prevent unexpected failures and ensure continuous operation of the industrial automation system.

Product Warranty

Schneider Electric offers a comprehensive warranty for the 140CPU67260 Unity Hot Standby Processor. The warranty coverage ensures that in case of any manufacturing defects, the product will be repaired or replaced free of charge within the specified warranty period. With a global support network, customers can access technical assistance at any time. Schneider Electric is committed to customer satisfaction and stands behind the quality of the 140CPU67260. The company’s extensive experience in industrial automation gives customers confidence in the reliability of the product. Whether it’s a small – scale industrial setup or a large – scale enterprise, the warranty on the 140CPU67260 provides peace of mind, knowing that their investment is protected.
MKS 0100-01577 PCB Board: Precision Electronics for Industrial Control Solutions
2025-06-19 BY
IN Company News

Schneider Electric 140CPU67160 is a high – performance programmable logic controller (PLC)

Product Overview

The Schneider Electric 140CPU67160 is a high – performance programmable logic controller (PLC) designed to meet the demands of complex industrial automation scenarios. As part of the Modicon Quantum series, it plays a crucial role in automation setups by providing reliable control and efficient operation. This PLC is engineered to handle a wide array of control tasks, making it an invaluable asset in various industries. It can manage multiple input and output signals, allowing for seamless integration with sensors and actuators. The 140CPU67160 is highly adaptable, whether used in small – scale manufacturing lines or large – scale industrial plants, offering a stable and efficient control solution.

Technical Specifications

Parameter Value
Product Model 140CPU67160
Manufacturer Schneider Electric
Product Type Programmable Logic Controller (PLC)
Input Voltage 24 VDC
Power Consumption 5 W
Program Memory 2 MB
Execution Time 0.5 ms/k
Number of I/O Points 64 inputs, 64 outputs
Communication Interfaces Modbus, Ethernet/IP, Profibus
Operating Temperature Range – 10 °C to + 60 °C
Protection Rating IP20
Memory Capacity (RAM) 64 KB
Memory Capacity (Flash) 256 KB

Key Features and Benefits

The Schneider Electric 140CPU67160 offers several distinct features that set it apart. Its high – speed processing capabilities ensure rapid response times. With an execution time of 0.5 ms per k instruction, it can handle critical processes without delay. The 2 MB of program memory provides extensive space for complex control logic programming. This means that even the most intricate control tasks can be executed smoothly.

ABB 3HAC060919-001 Connectors Digital; Manufacturer: ABB

The 140CPU67160 supports multiple communication interfaces such as Modbus, Ethernet/IP, and Profibus. This wide range of connectivity options enables easy integration with other devices and systems in an industrial network. It allows for efficient data exchange, which is essential for real – time monitoring and control.



In terms of reliability, the PLC is built to last. It can operate within a relatively wide temperature range of – 10 °C to + 60 °C, making it suitable for harsh industrial environments. The IP20 protection rating safeguards it against dust and light splashes, further enhancing its durability.

Application Scenarios

In power plants, the Schneider Electric 140CPU67160 can be used to control the operation of various systems. For example, it can manage the start – up and shut – down sequences of generators, ensuring smooth transitions and preventing potential damage. In oil & gas refineries, it plays a vital role in controlling the flow of fluids through pipelines. By accurately processing input signals from sensors that monitor pressure, temperature, and flow rate, the 140CPU67160 can adjust valves and pumps to maintain optimal operating conditions.



In discrete manufacturing lines, such as those producing automotive parts, the PLC can control the movement of robotic arms. It can precisely time the actions of the arms to pick, place, and assemble components, increasing production efficiency and product quality. In smart infrastructure projects, like intelligent buildings, the 140CPU67160 can be used to manage lighting, heating, and ventilation systems. It can adjust these systems based on occupancy sensors and environmental conditions, leading to energy savings.

Related Models

  • 140CPU43412 – A previous – generation model with a lower processing speed and less memory capacity, suitable for less complex automation tasks.
  • 140CPU11302 – A more basic model with a simpler architecture, designed for small – scale applications where cost – effectiveness is a priority.
  • 140ACI04000 – An input module that can be used in conjunction with the 140CPU67160 to expand the number of input channels in an automation system.
  • 140CHS11000 – A communication module that enhances the networking capabilities of the 140CPU67160, providing additional options for data transfer within an industrial network.
  • 140CPS11400 – A power supply module that can be used to power the 140CPU67160 and other components in the same system, ensuring stable operation.

Installation and Maintenance

Installation preparation for the 140CPU67160 requires ensuring an appropriate physical space. The module has compact dimensions, but it should be installed in an area with enough room for proper ventilation. Grounding is crucial to protect the device from electrical surges. It should be mounted on a stable surface following the provided mounting instructions. The operating environment should be within the specified temperature range of – 10 °C to + 60 °C.

Phoenix Contact ASIQUINT 100-240/4.8EFD Power Supply

For maintenance, regular checks of the communication interfaces are recommended to ensure seamless data transfer. Monitoring the power consumption can also help detect any potential issues. The PLC should be inspected for any signs of physical damage. As for replacement intervals, the battery (if applicable) should be replaced according to the manufacturer’s guidelines. Software updates should be installed periodically to keep the 140CPU67160 running with the latest features and security patches.

Product Warranty

Schneider Electric stands behind the quality of the 140CPU67160 with a comprehensive warranty. The warranty coverage ensures that in case of any manufacturing defects, the product will be repaired or replaced. Global support is available, so customers anywhere in the world can access assistance. The company is committed to customer satisfaction and aims to resolve any issues promptly. Whether it’s a technical query or a warranty claim, Schneider Electric’s support team is ready to provide the necessary help, giving customers confidence in their investment in the 140CPU67160 for their industrial automation needs.
2025-06-19 BY
IN Company News

140CPU65160  is a high-performance central processing unit (CPU)

Product Overview

The 140CPU65160  is a high-performance central processing unit (CPU) from Schneider Electric’s Quantum series, designed for complex industrial automation systems. As the core control component, this CPU delivers robust processing power and reliability for managing critical operations in manufacturing, energy, and process industries. Part of the Quantum platform, the 140CPU65160 integrates seamlessly with modular I/O systems, enabling real-time data processing, logic control, and communication across distributed networks. Its value lies in its ability to handle high-speed applications, support redundant configurations, and ensure system stability even in harsh industrial environments. The 140CPU65160 typically serves as the brain of automation setups, coordinating machine functions, optimizing workflow efficiency, and facilitating predictive maintenance through advanced diagnostic capabilities. This model stands out for its balance of processing speed, memory capacity, and compatibility with industry-standard protocols, making it a cornerstone for scalable and reliable control systems.

Technical Specifications

Parameter Value
Product Model 140CPU65160
Manufacturer  Schneider Electric
Product Type Industrial PLC CPU (Central Processing Unit)
Processor Type 32-bit RISC processor
Memory 8 MB user program memory, 8 MB data memory
Communication Protocols Modbus, Ethernet/IP, Quantum Data Highway (QDH), Profibus
Power Supply 24V DC (±10%)
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Dimensions 114 mm (H) x 25 mm (W) x 175 mm (D)
Mounting Method Rack-mounted (DIN rail)
Protection Class IP20 (indoor use)
I/O Support Up to 16,384 I/O points (via expansion modules)

Key Features and Benefits

The 140CPU65160 140CPU65160 offers the industrial sector several critical advantages that enhance operational efficiency. Its high-speed processing capability ensures rapid execution of complex logic programs, reducing cycle times and improving machine responsiveness. The CPU’s built-in redundancy support—such as hot standby and automatic failover—minimizes downtime in mission-critical applications, making it ideal for systems where reliability is non-negotiable. Additionally, the model features advanced self-diagnostic functions that monitor hardware health, detect faults, and provide real-time error reporting, enabling proactive maintenance and reducing troubleshooting time.
Kawasaki P/N 50979-0360L05 Teach Pendant Cable - Industrial Control Solutions

In terms of flexibility, the 140CPU65160140CPU65160 supports multiple programming languages (including ladder logic, structured text, and function block diagrams), catering to diverse engineering preferences. Its compatibility with Schneider Electric’s Unity Pro software simplifies system configuration, programming, and commissioning. The CPU also prioritizes cybersecurity with embedded access control and data encryption, safeguarding against unauthorized system intrusion. Furthermore, its modular design allows seamless integration with existing Quantum components, facilitating system upgrades without major overhauls. These features combined make the 140CPU65160 a future-proof solution for industries demanding high-performance, secure, and adaptable automation control.

Application Scenarios

The 140CPU65160thrives in a wide range of industrial environments where precise, reliable control is essential. In manufacturing, it powers assembly lines for automotive plants, managing robotic arms, conveyor systems, and quality inspection stations to ensure consistent production output. In oil and gas refineries, the CPU oversees complex processes like distillation and pipeline monitoring, operating in harsh conditions while maintaining real-time data exchange with supervisory control and data acquisition (SCADA) systems.
Xu Gong AK-BX556M Control/Interface Module - Reliable Automation Solutions

For power generation facilities, the 140CPU65160 regulates turbine operations, grid synchronization, and energy distribution, ensuring stable power supply. It also excels in water treatment plants, controlling pumps, valves, and filtration systems to optimize water quality and flow rates. In smart infrastructure, such as metro rail networks, the CPU manages train signaling, platform screen doors, and environmental control systems for safe and efficient transit. Its ability to handle high I/O counts and support redundant networks makes it suitable for any application requiring continuous operation, from food and beverage processing to pharmaceutical manufacturing. By integrating the 140CPU65160, industries can achieve higher productivity, reduced operational costs, and enhanced system visibility.

Related Models

  • 140CPU65260 – Higher-performance variant with increased memory and processing speed for complex applications.
  • 140CPU43412 – Entry-level Quantum CPU for smaller-scale systems with basic control needs.
  • 140CPU67160 – Redundant CPU model designed for fault-tolerant systems requiring zero downtime.
  • 140CPU65150 – Previous generation model with similar functionality but lower memory capacity.
  • 140XBP01600 – Quantum backplane compatible with 140CPU65160 for modular system expansion.
  • 140NOE77101 – Ethernet communication module to enhance network connectivity for the 140CPU65160.
  • 140CPS11420 – Power supply unit designed to complement the 140CPU65160 in Quantum control systems.

Installation and Maintenance

Installation Preparation: Before installing the 140CPU65160, ensure the mounting area is free of dust, moisture, and vibrations, as these can impact performance. The CPU mounts vertically on a DIN rail within a control cabinet, requiring at least 25 mm of clearance on all sides for proper ventilation. Grounding the cabinet to industry standards (e.g., IEC 60364) is crucial to prevent electrical interference. Verify the power supply matches the CPU’s 24V DC requirements and that all wiring complies with local electrical codes. Connecting the CPU to a Quantum backplane should follow manufacturer guidelines to ensure secure module alignment and communication.


Maintenance Recommendations: Regular maintenance of the 140CPU65160 involves periodic visual inspections for loose connections or physical damage. Use diagnostic tools within Unity Pro software to monitor CPU health, including memory usage, processor load, and error logs. Perform firmware updates as recommended by Schneider Electric to address security patches and feature enhancements. In dusty environments, clean the CPU’s ventilation slots quarterly to prevent overheating. While the CPU is designed for long-term reliability, consider having a spare 140CPU65160 on hand for critical systems to minimize replacement delays in the event of a failure. Always power down the system and follow ESD (electrostatic discharge) precautions when handling the CPU.

Product Warranty

Schneider Electric stands behind the 140CPU65160 with a comprehensive warranty that reflects its commitment to quality and durability. The product is guaranteed against defects in materials and workmanship for a period of [insert standard warranty duration, e.g., “two years”] from the date of purchase. During this period, Schneider Electric will repair or replace any faulty components at no cost, provided the product is used in accordance with operational guidelines. Customers benefit from global technical support, including access to online resources, product documentation, and expert assistance to address installation, configuration, or maintenance queries. The warranty underscores the 140CPU65160’s reliability in demanding industrial settings and reinforces Schneider Electric’s dedication to customer satisfaction, ensuring peace of mind for users investing in this automation solution.
EMERSON PR9268/203-000
EMERSON PR9268/617-100
EMERSON PR9268-200-000
EMERSON PR9268-300-000
EMERSON PR9350/02
ABB DSSR122 Power Supply Unit for DC-input
2025-06-19 BY
IN Company News

Schneider Electric 140CPU65150 | high – performance unity processor

Product Overview

The 140CPU65150 is a high – performance unity processor from Schneider Electric’s Modicon Quantum series. It plays a crucial role in industrial automation setups as the central processing unit. This processor combines the standard functionality of a PLC with the diagnostic capabilities of a web server, which is a significant advantage. It communicates using an RJ – 45 connection, enabling seamless integration with various network components.



The 140CPU65150 is designed to handle complex control tasks efficiently. With its powerful processing architecture, it can execute control algorithms rapidly, ensuring smooth operation of industrial processes. Its presence in the Modicon Quantum series, known for its reliability and high – end performance, further validates its value in industrial applications. Whether it’s for small – scale control systems or large – scale, multi – faceted automation projects, the 140CPU65150 offers the necessary capabilities to meet the demands of modern industrial environments.

Technical Specifications

Parameter Value
Product Model 140CPU65150
Manufacturer Schneider Electric
Product Type Unity Processor
Clock Frequency 166 MHz
Number of Local Racks 2
Distributed I/O Stations 63 (1 rack, 3 Modbus Plus networks)
Remote I/O Stations 31 (2 s908 remote I/O racks), 31 (2 Ethernet Quantum remote I/O racks), 16 (2 Ethernet x80 remote I/O racks)
Discrete I/O (Distributed) 8000 inputs, 8000 outputs per Modbus Plus network
Discrete I/O (Remote) 31744 inputs, 31744 outputs
Analogue I/O (Distributed) 500 inputs, 500 outputs per Modbus Plus network
Memory (Internal RAM) 768 kb
Expandable Program Memory 7168 kb with PCMCIA card
Expandable File Storage 8 mb with PCMCIA card
Communication Interfaces Ethernet TCP/IP, Modbus, Modbus Plus, USB
Bus Current Requirement 2160 mA

ABB YXU 169FYT204001-JT Industrial Control Module

Key Features and Benefits

The 140CPU65150 offers several practical strengths. Its high clock frequency of 166 MHz allows for rapid data processing. This speed is essential in applications where quick decision – making and response times are critical, such as in high – speed manufacturing lines. The processor’s large internal RAM of 768 kb, along with expandable program and file storage, enables it to handle extensive programs and data storage requirements. This is beneficial for complex industrial processes that involve large amounts of data and numerous control algorithms.



In terms of communication, the 140CPU65150 comes with multiple integrated connection types like Ethernet TCP/IP, Modbus, Modbus Plus, and USB. This variety of interfaces makes it highly interoperable, allowing it to communicate with different devices and systems within an industrial network. It can easily integrate with other Schneider Electric components as well as third – party devices, providing a comprehensive solution for modern automation needs.



The built – in diagnostic capabilities, through its web server functions (although service configuration requires software), help in efficient troubleshooting. This reduces downtime as maintenance personnel can quickly identify and address issues. The processor’s modular design also contributes to its flexibility and scalability. It can be easily expanded by adding optional modules such as Ethernet, Modbus, Modbus Plus, Profibus DP, and Sy/Max, adapting to the evolving needs of industrial operations.

Application Scenarios

In manufacturing automation, the 140CPU65150 can be used to optimize control and monitoring in production lines. For example, in an automotive manufacturing plant, it can control the robotic arms that assemble car parts. Its high – speed data processing capabilities ensure that the robots move precisely and quickly, increasing production efficiency and product quality.



In the energy sector, such as in power plants, the 140CPU65150 can manage the complex processes of power generation and distribution. It can monitor and control the operation of turbines, ensuring they run at optimal levels. In oil and gas refineries, it can be used to control the flow of fluids through pipelines, adjusting valves and pumps in real – time based on various parameters like pressure and temperature.

ABB DSSR122 Power Supply Unit for DC-input

For building management systems, the 140CPU65150 can enhance operational control and energy efficiency. It can control heating, ventilation, and air – conditioning (HVAC) systems, adjusting the temperature and air quality based on occupancy and environmental conditions. This not only improves the comfort of building occupants but also helps in reducing energy consumption.

Related Models

  • 140CPU65260: An upgrade of the 140CPU65150 with enhanced processing power, suitable for even more complex and demanding industrial applications.
  • 140CPU43412: A previous – generation model with lower processing speed and memory capacity, often used in less complex automation setups.
  • 140CRA93200: A companion module that provides additional communication capabilities for the 140CPU65150, expanding its network connectivity options.
  • 140CRP93200: This module offers redundancy features when used with the 140CPU65150, enhancing the reliability of the overall system in critical applications.
  • 140NOE77101: An Ethernet communication module that can be added to the 140CPU65150 to improve its Ethernet – related communication performance and functionality.

Installation and Maintenance

Installation preparation: Before installing the 140CPU65150, ensure there is sufficient physical space in the control cabinet. The module is in a double – width standard Quantum housing and requires two sequential slots in a Quantum rack. Proper grounding is essential to protect the module from electrical interference. The installation environment should be free from excessive dust, moisture, and extreme temperatures, as the module is designed to operate within specific environmental conditions. Mounting the module should follow the standard procedures for Quantum series components, ensuring a secure fit.



Maintenance recommendations: Regularly check the status LEDs on the 140CPU65150 to monitor its operation. These LEDs can indicate issues such as communication problems or hardware malfunctions. Periodically perform diagnostic tests using the Unity Pro software, which is compatible with the 140CPU65150. This software can provide detailed information about the module’s performance and help detect any potential issues early. The replacement intervals for components such as the battery (if applicable) should be based on the manufacturer’s guidelines. Also, keep the module clean and free from debris to ensure optimal performance.

Product Warranty

Schneider Electric stands behind the quality of the 140CPU65150 with a comprehensive warranty. The exact details of the warranty coverage can be obtained from authorized Schneider Electric dealers or service centers. In case of any issues during the warranty period, customers can rely on Schneider Electric’s global support network. The company is committed to customer satisfaction and will work promptly to resolve any problems related to the 140CPU65150. Whether it’s providing technical assistance or replacing a defective unit, Schneider Electric ensures that its customers can continue to use the 140CPU65150 with confidence in their industrial automation setups.
2025-06-19 BY
IN Company News

Schneider 140CPU43412A is a high – performance programmable logic controller (PLC)

Product Overview

The Schneider 140CPU43412A is a high – performance programmable logic controller (PLC) that plays a pivotal role in the Modicon Quantum automation platform. This central controller is designed to meet the complex demands of industrial automation. It serves as the brain of the system, efficiently handling control logic and making critical decisions for a wide range of industrial processes. With its advanced capabilities, the 140CPU43412A can execute complex control algorithms and manage data processing tasks, ensuring the smooth operation of automated systems. Its role in an automation setup is to connect and control various industrial equipment such as motors, pumps, and valves, providing real – time monitoring and control. This makes it a valuable asset in industries where precision, reliability, and high – speed data processing are essential.

Technical Specifications

Parameter Value
Product Model 140CPU43412A
Manufacturer Schneider
Product Type Processor
Processor Name 80486 Mathematical Coprocessor
Clock Frequency 66 MHz
Memory Description Internal RAM 896 kb
Exact Time for 1 KInstruction 0.1 – 0.5 ms
Watchdog Timer 250 ms
Clock Drift ±8 s/day at 0 – 60 °C
I/O Words (Max Local) 64 I / 64 O
I/O Words (Remote) 64 I / 64 O
I/O Words (Distributed) 30 I / 32 O
Distributed Drops / Network 63
Distributed Number of Drops 31
Remote Number of Network 2
Battery Type Lithium 7 μA 210 μA
Battery Capacity 1.2 ah
Battery Life 10 yr
Number of Ports 1 Modbus Plus, 2 Modbus RS232
Communication Module Processor Capacity 6 NOM, NOE, CR, NMS
Switch Function Key Switch
Marking CE
Bus Current Requirement 1250 mA
Module Format Standard
Product Weight 1.87 lb (0.85 kg)
Ambient Air Temperature for Operation 32 – 140 °F (0 – 60 °C)
Ambient Air Temperature for Storage – 40 – 185 °F (- 40 – 85 °C)
Relative Humidity 95% without condensation
Operating Altitude ≤16404.2 ft (5000 m)

Key Features and Benefits

The 140CPU43412A offers several key features that set it apart in the industrial automation landscape. Its high – performance 80486 processor, running at 66 MHz, enables rapid execution of control programs. This results in fast response times, which are crucial for real – time control applications. For example, in a high – speed manufacturing line, the 140CPU43412A can quickly process sensor data and adjust the operation of machinery to maintain optimal production rates.

Bently 330-980-71-05 Proximity Probe System, Industrial Vibration Monitoring

The controller has an internal RAM of 896 kb, providing ample space for storing control programs and data. This large memory capacity allows for the implementation of complex control strategies. In a petrochemical plant, the 140CPU43412A can store and manage vast amounts of process data, ensuring accurate control of chemical reactions.



With one Modbus Plus and two Modbus RS232 ports, the 140CPU43412A offers excellent communication capabilities. It can easily integrate with other industrial devices such as HMIs, other PLCs, and sensors. This seamless integration enhances the overall functionality of the automation system, allowing for better data exchange and coordinated operation.



The lithium – powered battery, with a capacity of 1.2 ah and a lifespan of 10 years, ensures that the controller can retain program and data during power outages. This feature is vital in industries where continuous operation is critical, like power generation, where any interruption could lead to significant disruptions.

Application Scenarios

The Schneider 140CPU43412A finds applications in a wide range of industries. In the manufacturing sector, it is used to control assembly lines. For instance, in an automotive manufacturing plant, the 140CPU43412A can manage the operation of robotic arms, conveyor belts, and other automated equipment. It ensures that parts are assembled accurately and efficiently, leading to high – quality production.

Bently 330-980-71-05 Proximity Probe System, Industrial Vibration Monitoring

In power plants, the 140CPU43412A plays a crucial role in monitoring and controlling power generation processes. It can regulate the operation of turbines, generators, and other power – related equipment. By processing data from various sensors, it ensures stable power output and helps in detecting and preventing potential equipment failures.



In water treatment plants, this controller is used to automate the treatment process. It can control the opening and closing of valves, the operation of pumps, and the monitoring of water quality parameters. For example, it can adjust the dosage of chemicals based on the real – time water quality data, ensuring that the treated water meets the required standards.



In the oil and gas industry, the 140CPU43412A is used in refineries to control complex processes such as distillation and cracking. It can manage the flow of crude oil and its derivatives, ensuring safe and efficient operation of the refinery.

Related Models

  • 140CPU43412U: This is the replacement model for the 140CPU43412A, likely offering enhanced features or improved performance.
  • 140CPU31110: It is a part of the Quantum PLC family, but with different processing capabilities and features compared to the 140CPU43412A, perhaps suitable for less complex applications.
  • 140CPU53414A: Another Quantum PLC processor, it may have different memory configurations or communication capabilities, making it more suitable for specific industrial scenarios compared to the 140CPU43412A.
  • 140CPU65150: This model has the ability to use aux tasks numbered 0 thru 3, which is different from the 140CPU43412A that only allows a fast and a mast task, thus catering to different programming requirements.
  • 140CPU67160: It also supports aux tasks and has features that may be more suitable for large – scale, high – performance industrial automation setups compared to the 140CPU43412A.

Installation and Maintenance

Installation preparation for the 140CPU43412A requires ensuring there is sufficient physical space within the control cabinet. The cabinet should be well – ventilated to maintain an appropriate operating temperature range of 32 – 140 °F (0 – 60 °C). Proper grounding is essential to protect the controller from electrical surges and ensure reliable operation. The 140CPU43412A has a standard module format, which simplifies the mounting process. It can be easily installed in a rack – based system following the provided installation guidelines.



For maintenance, regular checks should be carried out on the communication ports to ensure there are no issues with data transfer. The battery, located on the front of the cpu, should be inspected periodically. Although it has a lifespan of 10 years, visual inspection can help detect any signs of leakage or degradation. The memory – protect switch should also be checked to ensure it is functioning correctly to safeguard the application program. In case of any hardware failures, the modular design of the 140CPU43412A allows for easy replacement of faulty components without disrupting the entire system.

Product Warranty

We are confident in the quality of the Schneider 140CPU43412A. It comes with a comprehensive warranty that reflects our commitment to customer satisfaction. In the unlikely event of a defect in materials or workmanship, we will provide prompt support. Our global support network is available to assist customers around the world. Whether it’s a technical query or a warranty claim, our team of experts is ready to help. The warranty period ensures that you can rely on the 140CPU43412A for a significant period, providing peace of mind and protection for your investment in this high – performance industrial controller.
DAIHEN FLB-60M-03 | PLC Module, for Industrial Automation
2025-06-19 BY
IN Company News

Schneider Electric 140CPU43412U  | high – performance Unity processor crafted by Schneider Electric

Product Overview

The 140CPU43412U is a high – performance Unity processor crafted by Schneider Electric for the Modicon Quantum automation platform. This module plays a pivotal role in industrial automation setups. With a 66MHz clock frequency, it can rapidly execute complex control algorithms, making it suitable for applications that demand high – speed processing. It has an internal RAM of 1056KB, which allows for the storage and manipulation of large – scale programs and data, crucial for handling intricate industrial processes. In an automation system, the 140CPU43412U serves as the brain, coordinating the operations of various components. Its ability to manage multiple tasks simultaneously, such as 64 interrupt tasks, 64 I/O interrupt tasks, 16 timer interrupt tasks, 1 periodic fast task, and 1 cyclic/periodic main task, ensures seamless operation of the overall system. This processor is highly valuable due to its combination of processing power, memory capacity, and multitasking capabilities, enabling industries to enhance productivity and efficiency in their automation processes.

Technical Specifications

Parameter Value
Product Model 140CPU43412U
Manufacturer Schneider Electric
Product Type Unity Processor
Clock Frequency 66MHz
Internal RAM 1056KB
Program Memory (Max) 1280KB
Communication Protocols Modbus TCP/IP, Modbus Plus, Ethernet
Input Voltage 24VDC
Operating Temperature Range 0 °C to 60 °C (32 °F to 140 °F)
Storage Temperature Range – 40 °C to + 85 °C (- 40 °F to + 185 °F)
Humidity 5% to 95% RH, non – condensing
Vibration 0.5 g rms, 5 to 500 Hz
Shock 15 g, 11 ms half – sine pulse
Dimensions (W x H x D) 90 mm x 130 mm x 120 mm
Weight Approximately 0.7 kg (1.54 lbs)

Key Features and Benefits

The 参offers several notable features and benefits. Its 66MHz high – performance processor enables rapid instruction execution, with each instruction taking between 0.1 – 0.585μs. This speed ensures quick response times in industrial control scenarios, reducing system latency and improving overall process efficiency. The 1056KB of internal RAM provides ample space for storing programs and data. This large memory capacity allows for the implementation of complex control strategies and the handling of extensive datasets, which is essential for modern industrial applications.

DAIHEN FLB-60M-03 | PLC Module, for Industrial Automation

In terms of communication, the 140CPU43412U supports multiple protocols like Modbus TCP/IP, Modbus Plus, and Ethernet. This versatility makes it easy to integrate with other devices in the industrial network, such as sensors, actuators, HMIs, and other PLCs. It also has 1 Modbus Plus and 2 Modbus communication ports as standard, and additional communication interfaces like Ethernet TCP/IP and Profibus DP can be added via optional modules. This flexibility in communication ensures seamless data exchange across the entire automation system.
The processor is designed to be rugged and reliable, capable of operating in harsh industrial environments. With an operating temperature range of 0 °C to 60 °C and the ability to withstand humidity, vibration, and shock, it can maintain stable performance even in challenging conditions. This reliability reduces the risk of system failures and downtime, saving both time and money for industrial operations.

Application Scenarios

The 140CPU43412U finds extensive use in various industrial applications. In power plants, it can be used to control the operation of turbines, generators, and other critical equipment. For example, it can monitor and regulate the speed of turbines based on real – time data from sensors, ensuring optimal power generation efficiency. By processing data from multiple sensors regarding temperature, pressure, and flow, the 140CPU43412U can make precise control decisions to maintain the stable operation of the power plant.



In oil & gas refineries, this processor is crucial for controlling the refining processes. It can manage the opening and closing of valves, the operation of pumps, and the monitoring of chemical reactions. For instance, during the distillation process, the 140CPU43412U can adjust the temperature and flow rates in real – time to ensure the production of high – quality refined products. It can also integrate with safety systems to detect and respond to any potential leaks or abnormal conditions promptly.



In discrete manufacturing lines, such as automotive production, the 140CPU43412U controls the movement of robots, conveyor belts, and other machinery. It coordinates the assembly process, ensuring that parts are delivered to the right location at the right time. For example, in a car assembly line, it can control the movement of robotic arms to accurately install components like engines and doors, enhancing production speed and quality.

Related Models

  • 140CPU43412AC: An alternative variant with potentially different power or communication capabilities, perhaps optimized for specific industrial power requirements.
  • 140CPU31110: A related model with different processing power and memory configuration, likely suitable for less complex industrial automation tasks where lower – end processing capabilities are sufficient.
  • 140CPU11302: An earlier – generation model with basic functionality, having a lower clock speed and less memory compared to the 140CPU43412U, suitable for simpler automation setups.
  • 140CPU53414B: A model with enhanced features, possibly more memory or advanced communication options, catering to applications with higher – end requirements than the 140CPU43412U.
  • 140CPU65160: A more powerful model within the Quantum family, with higher processing speeds and larger memory, designed for extremely complex industrial control systems.

Installation and Maintenance

Installation preparation for the 140CPU43412U requires ensuring an appropriate physical space. The module has dimensions of 90 mm x 130 mm x 120 mm, so it should be installed in an area that can accommodate its size. Grounding is essential to protect the module from electrical surges. A proper grounding connection should be established according to industry standards. The operating environment should be within the specified temperature range of 0 °C to 60 °C and humidity range of 5% to 95% RH, non – condensing. The module can be mounted using standard mounting methods suitable for industrial control components, ensuring a secure fit.

ABB AO561: Precision Analog Input Module for Industrial Automation

For maintenance, regular checks should be carried out. Monitor the module’s temperature during operation to ensure it remains within the specified range. Check for any signs of physical damage, such as cracks or loose connections. Diagnostic software can be used periodically to assess the module’s performance and detect any potential issues. In terms of replacement intervals, while the 140CPU43412U is designed for long – term reliability, if there are repeated malfunctions or signs of degradation, it may be time to consider replacement. However, with proper care and maintenance, it can serve industrial applications for many years.

Product Warranty

We stand firmly behind the quality of the 140CPU43412U. This processor comes with a comprehensive warranty that reflects our confidence in its durability and performance. In the unlikely event of a defect in materials or workmanship, our global support network is readily available to assist. Our commitment to customer satisfaction means that we will work closely with you to resolve any issues promptly. Whether it’s providing replacement parts or offering technical advice, we strive to minimize any disruptions to your industrial operations. With our warranty coverage, you can invest in the 140CPU43412U with peace of mind, knowing that you are backed by a company dedicated to providing top – notch products and support.
2025-06-19 BY
IN Company News

Schneider Electric 140CPU31110  | high-performance unity processor module

Product Overview

The 140CPU31110 is a high-performance unity processor module designed by Schneider Electric for the Modicon Quantum automation platform. As a crucial component in industrial automation setups, it serves as the central processing unit that controls and monitors various processes. This processor plays a pivotal role in ensuring the seamless operation of industrial systems, from managing complex production lines to overseeing intricate machinery.



Within the Modicon Quantum series, the 140CPU31110 stands out for its ability to handle diverse tasks efficiently. It processes data, executes control programs, and enables smooth communication with other devices in the automation system. Its presence in an industrial setup is invaluable, as it helps enhance productivity, improve system reliability, and optimize overall performance.

Technical Specifications

Parameter Value
Product Model 140CPU31110
Manufacturer Schneider Electric
Product Type Unity Processor
Number of Racks 2 local racks
Optional Modules 2 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)
Internal RAM 548 kb
Bus Current Requirement 1800 mA
Operating Temperature -10 °C to 55 °C
Protection Class IP20
Speed (Clock) 66 MHz
Boolean Instructions/ms 1.86 k
Display Type LCD
Net Weight 0.77 kg

Bently 330-980-71-05 Proximity Probe System, Industrial Vibration Monitoring

Key Features and Benefits

The 140CPU31110 offers several practical strengths that set it apart. Its high – speed 66 MHz clock enables rapid data processing, allowing it to execute complex control tasks with precision and speed. This is particularly beneficial in applications where real – time response is critical, such as in high – speed production lines.



With 548 kb of internal RAM, it has ample space to store programs and data, facilitating the implementation of intricate control strategies without performance degradation. The support for multiple communication protocols like Ethernet, Modbus, Modbus Plus, Profibus DP, and Sy/Max makes it highly versatile. It can integrate seamlessly with different devices and systems within an industrial plant, enhancing interoperability and control.



This processor also features a conformal coating, which provides enhanced protection against dust, moisture, and corrosive substances. This makes the 140CPU31110 suitable for use in harsh industrial environments, ensuring reliable operation and minimizing downtime. Additionally, its ability to support up to two local racks and accommodate various optional modules allows for easy customization according to specific project requirements.

Application Scenarios

In manufacturing industries, the 140CPU31110 is widely used. For example, in automotive manufacturing plants, it can control robotic arms during the assembly process. It precisely coordinates the movements of these robots, ensuring accurate part placement and high – quality product assembly. This results in increased production speed and reduced errors.



In power generation facilities, the 140CPU31110 monitors and controls the power generation process. It regulates the operation of generators, ensuring stable power output. It also manages the distribution of electricity, optimizing energy flow and reducing power losses.

Bently 330-980-71-05 Proximity Probe System, Industrial Vibration Monitoring

Within the oil and gas industry, this processor is used to control and monitor equipment such as pumps and valves. It ensures the proper flow of oil and gas through pipelines by accurately controlling the opening and closing of valves and the speed of pumps. This helps maintain the efficiency and safety of the entire oil and gas production process.

Related Models

  • 140CPU43412: An upgraded version with higher processing power and more advanced features, suitable for larger – scale and more complex industrial applications.
  • 140CPU11302: A previous – generation model with basic control capabilities, often used in simpler industrial setups where cost – effectiveness is a priority.
  • 140CPS11420: A power supply module that is compatible with the 140CPU31110, ensuring stable power delivery to the processor and the overall Modicon Quantum system.
  • 140NOE77101: An Ethernet communication module that can be added to the 140CPU31110 setup to enhance network connectivity and enable seamless integration with other Ethernet – based devices in the industrial network.
  • 140ACI04000: An analog input module that can be paired with the 140CPU31110 to handle analog signals in industrial processes, expanding the system’s input capabilities.

Installation and Maintenance

Installation preparation for the 140CPU31110 requires a suitable physical space within the control cabinet. Ensure there is enough room for proper ventilation to prevent overheating, as the operating temperature range is -10 °C to 55 °C. The mounting method typically involves using standard DIN rails, which provide a secure and easy – to – install solution. Proper grounding is also essential to protect the processor from electrical surges and ensure stable operation.



For maintenance, it is recommended to regularly check the status of the processor using the built – in diagnostic tools. This includes monitoring for any error messages on the LCD display. Periodic inspections of the connections and cables should be carried out to ensure they are secure. Although the 140CPU31110 is a reliable device, it is advisable to consider replacement every 5 – 7 years, depending on the operating environment and usage intensity, to maintain optimal performance.

Product Warranty

We are confident in the quality of the 140CPU31110. It comes with a comprehensive warranty that covers any manufacturing defects for a period of [X] years. Our global support team is available around the clock to assist with any issues related to the product. Whether it’s a technical query during installation or a problem during operation, our experts are just a call or an email away. We are committed to ensuring customer satisfaction and will work closely with you to resolve any concerns promptly. Our goal is to provide you with a reliable and high – performing product that you can trust for your industrial automation needs.
2025-06-19 BY
IN Company News

Schneider 140CPU11303 | Schneider

Product Overview

The 140CPU11303 is a  that forms an integral part of the Schneider Electric Modicon Quantum automation platform. This platform is widely recognized in the industrial automation domain for its reliability and versatility.



Functionally, the 140CPU11303 is responsible for executing control logic, processing data, and managing communication within an industrial control system. With its advanced architecture, it can handle a wide range of control applications, from discrete and analog control to complex process control scenarios. In an automation setup, it serves as the brain, coordinating the activities of various input/output (I/O) modules and other components. What makes the 140CPU11303 truly valuable is its ability to offer high – speed processing, ensuring real – time response in industrial processes. It also provides excellent compatibility with a vast array of industrial devices, making it suitable for both new installations and retrofitting existing systems.

Technical Specifications

Parameter Value
Product Model 140CPU11303
Manufacturer Schneider
Product Type CPU Module
Processor Intel 80186
Clock Speed 20 MHz
Memory 368 kb Internal RAM
Communication Ports 1 Modbus Plus, 1 Modbus RS232
I/O Points (Distributed) 30 I / 32 O
I/O Points (Max Local) 64 I / 64 O
I/O Points (Remote) 64 I / 64 O
Networking (Distributed Networks) Up to 3
Networking (Remote Networks) Up to 2
Battery Type Lithium, 7 µA – 210 µA
Battery Capacity 1.2 Ah
Battery Life 10 years
Operating Temperature 0 – 60°C (32 – 140°F)
Storage Temperature – 40 – 85°C (- 40 – 185°F)
Humidity 95% without condensation
Operating Altitude ≤ 5000 m (≤ 16404.2 ft)



Key Features and Benefits

The 140CPU11303 comes with several remarkable features that set it apart in the industrial automation landscape. Its high – performance Intel 80186 processor enables rapid execution of control programs. With a clock speed of 20 MHz, it can handle complex algorithms and large amounts of data in real – time, ensuring smooth operation of industrial processes.



In terms of memory, the 368 kb of internal RAM provides ample space for storing both the control logic and the data being processed. This is crucial for applications that require significant computational power and data storage capabilities.



The module’s communication capabilities are also a major strength. The inclusion of one Modbus Plus and one Modbus RS232 port allows for seamless integration with other devices in the industrial network. This makes it easy to connect to sensors, actuators, HMIs, and other control systems, facilitating efficient data transfer and system – wide communication.

ABB YXU 169FYT204001-JT Industrial Control Module

The 140CPU11303 is highly reliable, with a long – lasting lithium battery that has a capacity of 1.2 Ah and a lifespan of 10 years. This battery backup ensures that important data is not lost during power outages, maintaining the integrity of the control system. Additionally, its robust construction and wide operating temperature range make it suitable for use in harsh industrial environments.

Application Scenarios

The 140CPU11303 finds extensive use across various industries. In the manufacturing sector, it is commonly employed in discrete manufacturing lines. For example, in an automotive assembly plant, the 140CPU11303 can be used to control the movement of robotic arms that perform tasks such as welding, painting, and part assembly. It precisely coordinates the actions of different components in the production line, ensuring high – quality and efficient manufacturing.



In the oil and gas industry, it plays a vital role in refineries. It can be used to monitor and control the complex processes involved in refining crude oil, such as distillation, cracking, and chemical reactions. The 140CPU11303 can process data from numerous sensors placed throughout the refinery, adjusting process parameters in real – time to optimize production and ensure safety.



Power plants also rely on the 140CPU11303 for their control systems. It can manage the generation, distribution, and monitoring of electrical power. For instance, it controls the operation of turbines, generators, and other power – related equipment, ensuring stable power output and efficient plant operation. In smart infrastructure projects, like intelligent building management systems, the 140CPU11303 can be used to control lighting, heating, ventilation, and air – conditioning systems, providing energy – efficient and comfortable environments.

Related Models

  • 140CPU11303S – An upgraded version with expanded IEC programming capacity. This model is ideal for applications that require more advanced programming features and greater flexibility in implementing complex control strategies.
  • 140CPU43412 – A more powerful variant with higher processing speed and larger memory capacity. It is suitable for large – scale industrial projects where more computational resources are needed to handle extensive control tasks.
  • 140CPU65160 – Offers enhanced networking capabilities compared to the 140CPU11303. This makes it a better choice for applications that involve complex network architectures and require high – speed data transfer between multiple devices.
  • 140CPU53414 – Features improved diagnostic capabilities, allowing for quicker identification and resolution of system faults. This is beneficial for industries where system uptime is critical, such as pharmaceutical manufacturing.
  • 140CPU11300 – An earlier generation model with basic functionality. It may be used in less complex industrial setups or as a cost – effective solution for projects with limited requirements.

Installation and Maintenance

Installation preparation for the 140CPU11303 requires ensuring an appropriate physical space. It should be installed in a location that allows for proper ventilation to prevent overheating, as it operates within a specific temperature range. The mounting method typically involves using standard DIN – rail mounting, which is a common and convenient way to secure the module in an industrial control panel. Grounding is also crucial to protect the module from electrical surges and ensure safe operation. The installation environment should be free from excessive dust, moisture, and electromagnetic interference.

ABB YXU 169FYT204001-JT Industrial Control Module

For maintenance, regular checks should be carried out. This includes monitoring the module’s operating temperature, as overheating can lead to performance degradation. Checking the communication ports for any signs of damage or poor connection is also important. Diagnostic software can be used to periodically assess the module’s health, looking for any error codes or abnormal behavior. As for replacement intervals, while the 140CPU11303 is designed for long – term use, the lithium battery should be replaced every 10 years as per its lifespan. In case of any hardware failures, it is advisable to consult Schneider Electric’s official documentation or contact their support team for proper replacement procedures.

Product Warranty

Schneider Electric stands behind the quality of the 140CPU11303 with a comprehensive warranty. The module is covered against defects in materials and workmanship for a specified period. This warranty not only gives customers confidence in the product’s quality but also reflects Schneider Electric’s commitment to customer satisfaction. In the unlikely event of a problem, their global support network is readily available. Customers can reach out to their local support centers or use online resources for assistance. Whether it’s troubleshooting, getting replacement parts, or seeking technical advice, Schneider Electric’s support team is dedicated to resolving issues promptly. This ensures that the 140CPU11303 continues to perform optimally throughout its lifespan, minimizing downtime and maximizing the efficiency of industrial operations.
PARKER PFVH35A25R2FN1 HYDRAULIC PUMP - High Efficiency Industrial Component
2025-06-19 BY
IN Company News

Schneider Electric 140CPU11302 | high – performance processor modul

Product Overview

The Schneider Electric 140CPU11302 is a high – performance processor module that plays a crucial role in industrial automation setups. It is part of the Modicon Quantum range, a well – known series in the industrial control domain. This module serves as the “brain” of the automation system, handling various control tasks with precision.



The 140CPU11302 uses a programmable memory to store user instructions. These instructions are then utilized to execute functions like logic operations, process sequencing, timing control, coupling, and arithmetic calculations. It enables control over digital and analog outputs, which are essential for managing different types of industrial machines and processes. In an automation setup, it acts as a bus master, overseeing the local, remote, and distributed I/O of the Quantum system, ensuring seamless data flow and operation.

Technical Specifications

Parameter Value
Product Model 140CPU11302
Manufacturer Schneider Electric
Product Type Control Processor Module
Processor 80186
Clock Speed 20 MHz
Internal RAM 109 kb
Local I/O 30 I / 32 O
I/O per Network 500 I / 500 O
Communication Ports 1 x Modbus RS232, 1 x Modbus Plus
Remote Branches Up to 31
Remote/Distributed Networks Up to 2 remote or 3 distributed
Battery Type Lithium
Battery Capacity 1.2 Ah
Battery Life 10 years
Operating Temperature 0 … 60 °C
Storage Temperature – 40 … 85 °C
Relative Humidity 95% non – condensing
Operating Altitude <= 5000 m
Bus Current Requirement 780 mA
Net Weight 0.3 kg

Key Features and Benefits

The 140CPU11302 offers several practical strengths. Its 80186 processor running at 20 MHz provides high – speed processing, enabling it to handle complex automation tasks with ease. This ensures quick response times, which is crucial in real – time industrial control scenarios. For example, in a fast – paced manufacturing line, the module can rapidly process commands to control the speed and movement of machinery.

PARKER PFVH35A25R2FN1 HYDRAULIC PUMP - High Efficiency Industrial Component

The module’s 109 kb of internal RAM is sufficient for storing program logic, data, and variables. This allows for efficient execution of control tasks without performance bottlenecks. Additionally, it has two communication ports (Modbus RS232 and Modbus Plus), providing versatile connectivity options. It can interface with a wide range of external devices and systems, facilitating seamless integration within an industrial network.



The lithium battery backup system is another advantage. With a capacity of 1.2 Ah and a lifespan of 10 years, it ensures uninterrupted operation and data retention, even during power disruptions. This is especially important in applications where continuous operation is critical, such as in power plants or oil refineries. The module’s robust design allows it to operate in a wide temperature range from 0 to 60 °C and a storage temperature range of – 40 to 85 °C. Combined with a relative humidity tolerance of 95% non – condensing and an operating altitude of up to 5000 m, it can withstand harsh industrial environments.

Application Scenarios

In manufacturing plants, the Schneider Electric 140CPU11302 is used to control production lines. For instance, in an automotive manufacturing facility, it can manage the robotic arms that assemble car parts. It precisely controls the movement of these arms, ensuring accurate and efficient assembly. The module’s ability to handle complex logic and timing functions is essential for coordinating the various steps in the assembly process.



Power plants also rely on the 140CPU11302 for their control systems. It can monitor and control the generation, transmission, and distribution of electricity. For example, it can regulate the speed of turbines based on the power demand. By processing real – time data from sensors, it adjusts the turbine’s operation to maintain a stable power supply.

PARKER PFVH35A25R2FN1 HYDRAULIC PUMP - High Efficiency Industrial Component

In the oil and gas industry, specifically in refineries, this module plays a vital role. It controls the various processes involved in refining crude oil, such as distillation and cracking. It ensures that the temperature, pressure, and flow rates are maintained within the required parameters. This helps in optimizing the refining process and ensuring the production of high – quality petroleum products.

Related Models

  • 140CPU11402: An upgraded version with enhanced processing power, suitable for more complex industrial applications that require higher computational capabilities.
  • 140CPU43412: A more advanced model in the Quantum range, offering greater memory capacity and more communication options, making it ideal for large – scale industrial automation projects.
  • 140CPU65160: Designed for high – end applications, it has a faster processor and improved I/O handling capabilities, which can be used in mission – critical industrial control systems.
  • 140CPS11420: A related power supply module that can be used in conjunction with the 140CPU11302 to ensure a stable power source for the automation system.
  • 140ACI03000: An analog input module that can be integrated with the 140CPU11302 to expand the system’s ability to handle analog signals, useful in applications where analog sensors are used.

Installation and Maintenance

Installation preparation for the 140CPU11302 requires ensuring an appropriate physical space. It has compact dimensions, but proper clearance should be provided for heat dissipation. The module should be mounted on a stable surface following the recommended mounting method, which usually involves using standard industrial mounting brackets. Grounding is crucial to protect the module from electrical interference and surges. The installation environment should be within the specified temperature and humidity ranges, from 0 to 60 °C for operation and – 40 to 85 °C for storage, with a relative humidity of 95% non – condensing.



For maintenance, regular checks should be carried out to ensure the module is operating within normal parameters. This includes monitoring the temperature of the module during operation, as overheating could indicate a problem. The battery should also be periodically inspected. Although it has a long lifespan of 10 years, early signs of battery degradation could affect the module’s performance. Diagnostic software can be used to check for any errors or malfunctions in the module. In case of any issues, replacement parts should be sourced from reliable suppliers. The module’s components are designed for durability, but over time, some parts may need to be replaced. It is recommended to keep spare parts on hand to minimize downtime in case of a failure.

Product Warranty

We are confident in the quality of the Schneider Electric 140CPU11302. It comes with a comprehensive warranty that reflects our commitment to customer satisfaction. In the unlikely event of a product defect, our global support network is ready to assist. Our support team is available to provide technical advice and guidance throughout the warranty period. If a replacement is required, we ensure a prompt and efficient service. We stand behind the reliability and performance of the 140CPU11302, and our warranty is a testament to our belief in the product’s quality. Whether you are using it in a small – scale manufacturing setup or a large – scale industrial plant, you can rely on the product’s performance and our support services.
Menu
Call us 24/7+86 19389860630

Search for products

Back to Top
Product has been added to your cart
phone: +86 19389860630
to whats
19389860630
to whats
19389860630
email: JLLucky33@qq.com
